Industrial Modem
H7910 5G Modem
  • 5G SA/NSA, support serial DTU function
  • Support multiple VPNs and security firewalls
  • Support 10/100/1000Mbps adaptive Gigabit LAN port
  • Embedded and light design meeting any installation requirements
Product Introduction
H7910 5G modem is developed based on high-performance hardware platform which supports 5G SA/NSA network and is downward compatible with 4G/3G network. It meets the requirements for Gigabit network ports, serial ports, and wireless GPS (optional) interfaces. The Gigabit LAN port supports 10/100/1000 MBPS auto-adaptation. Under actual measurement, the power consumption in online state is as low as 40mA@12V DC, and the highest speed is greater than 500Mbps. It has industrial design which is smaller in volume, lighter in weight and better in fitting. It can be used for all kinds of 5G application scenarios in various traditional and emerging industries.
Network
5G/4G/3G 5G Sub-6: N1, N3, N5, N7, N8, N20, N28, N38, N41, N77, N78, N79
4G LTE FDD: B1, B2, B3, B5, B7, B8, B20, B28
4G LTE TDD: B34, B38, B39, B40, B41, B42, B43*
3G WCDMA: B1, B2, B5, B8
Interface
Antenna Interface SMA-K SIM 1.8V/3.0V, Self-firing type
Serial Port RS232/RS485 5 Pin terminal 3.5mm
Button Reset RJ45 LAN, 10/100/1000Mbps adaptive
OTG Micro-USB
Power supply
Operating voltage +9V~+36V DC
Power consumption
Standby Power Consumption Approx. 40mA@12V DC
Operating Power Consumption Approx. 200mA@12V DC
Maximum Power Consumption Approx. 300mA@12V DC
Other
Weight Approx. 140g
Size 95.3×71.4×22.9 (mm)
Storage temperature -30~+75ºC
Operating temperature -45~+90ºC
Relative humidity ≤93%
File Name
Hongdian Datasheet-H7910 5G Modem-2023V1.0
