H7910 5G Router

  • 5G LAN Support
  • Dual Serial Ports
  • Compact & Lightweight
  • Comprehensive 5G Applications
Product Introduction
The H7910 is developed on a high-performance hardware platform, supporting 5G RedCap, 5G LAN, and 5G SA/NSA networking, with backward compatibility for 4G/3G network standards, enabling more flexible deployment. For interfaces, it features Gigabit Ethernet ports, serial ports, wireless GPS (reserved), and other essential connectivity options. In terms of product design, it adopts a new industrial-grade structure with a smaller size, lighter weight, and enhanced adaptability. The H7910 caters to both traditional and emerging industries for compact, embedded 5G application scenarios.
Advanced 5G Connectivity
  • · Supports 5G LAN, ultra-low latency, multi-channel dial-up, SA/NSA networks, and backward-compatible 4G/3G.
Industrial-Grade Interfaces
  • · Features Gigabit Ethernet, dual serial ports, routing, and serial DTU functionality.
Resilient Operation
  • · Dual hardware/software watchdogs with autonomous self-healing diagnostics.
Compact Embedded Design
  • · Minimal size/weight for space-constrained installations.
Hardware
CPU MIPS1004Kc @880 MHz
RAM 128MB
FLASH 16MB
Cellular Interface
Modem 1 x 5G NR SA&NSA/4G LTE/WCDMA
Number of antennas 4
Connector SMA-K
SIM 1 Mricro SIM card (optional esim 5X6)
Ethernet Interface
Number of ports 1
Configuration 1×WAN/LAN 10/100/1000Mbps, Gigabit Ethernet
Wireless interface
GPS interface Optional
Number of antennas 1
Connector SMA-K
Seiral interface
Type 1 RS-485, 1 RS-232
Socket form 1 x 7-pin 3.5 mm female socket
Signal definition RX,TX,GND (RS-232)
A+,B-,GND (RS-485)
Baudrate RS-232 (300-115200bps)
RS-485 (300-115200bps)
Software
Auto fail-over Between:
Cellular and WAN
Cellular and Wi-Fi (station mode)
WAN and Wi-Fi (station mode)
Network protocols PPP,PPPoE,TCP,UDP,IPv4,IPv6,SSL,DHCP,ICMP, NAT,HTTP,HTTPs, DNS, ARP,NTP,Telnet, SSH, DDNS, etc.
Network APN, VPDN, VLAN, QoS
Routing Static Routing, Policy routing, RIP, OSPF and BGP, etc
Firewall NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List
VPN PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN
Attack Prevention DDOS prevention, Anti port scanning
Ipsec Encryption DES, 3DES, AES128, AES192, AES256
OpenVPN Encryption BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC,
AES-192-CBC, AES-256-CBC, SEED-CBC
Remote Management HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Sandora Platform, SDLAN
Serial ports function Transparent, Modbus RTU, etc
Power Supply and Consumption
Power Connector 2-pin 3.5 mm Terminal
Voltage input +9V+36V DC
Power consumption Idle: 180mA@12V DC
Data transceiving:300mA@12V DC
Others
Reset button Yes
LED indicators 3 x indicators for PWR, NET, DATA
Hardware watchdog Yes
Physical Characteristics
Ingress protection IP30
Housing & Weight Aluminum shell, about 160g.
Dimension 111.3×71.4×22.4(mm)
Installations Desktop, Wall Mounting
Operating temperature -30 ~ +70 °C
Storage temperature -45 ~ +90 °C
Relative humidity 5 ~ 95% RH
EMC
ESD EN61000-4-2, level3
RS EN 61000-4-3, level3
EFT EN 61000-4-4, level3
CS EN 61000-4-6, level3
