| Product |
|
|
|
| Consumer Routers | H101C | A500Q | A500M |
| Cellular | |||
| Standard | 3GPP Rel-15 NSA/SA | 3GPP Release 16 NSA/SA | 3GPP Release 16 NSA/SA |
| Region | For EMEA and related countries | EMEA/Oceania/Brazil/North America | EMEA/Oceania/Brazil/North America |
| NR bands | NSA: n41/n78/n79, SA: n1/n28/n41/n77/n78/n79 |
5G NR: 3GPP Release 16 NSA/SA operation, Sub-6 GHz 5G NSA & SA: n1/n3/n5/n7/n8/n20/n28/n38/ n40/n41/n75/n76/n77/n78 |
5G NR: 3GPP Release 16 NSA/SA operation, Sub-6 GHz 5G NSA & SA: n1/n3/n5/n7/n8/n20/n28/n38/n40/n41/n75/n76/n77/n78 |
| LTE category | DL Cat 12/ UL Cat 13 |
DL 4 × 4 MIMO on: B1/B3/B7/B38/B40/B41/ B42/B43 |
DL 4 × 4 MIMO on:B1/B3/B7/B38/B40/B41/B42 |
| MIMO | DL 4 × 4 MIMO on: n1/n41/n77/n78/n79 |
5G DL 4×4 MIMO on: n1/n3/n7/n38/n40/n41/ n75/n76/n77/n78 LTE DL 4 × 4 MIMO on: B1/B3/B7/B38/B40/B41/ B42/B43 |
5G DL 4×4 MIMO on:n1/n3/n7/n38/n40/n41/n75/n76/n77/n78 LTE DL 4 × 4 MIMO on:B1/B3/B7/B38/B40/B41/B42 |
| LTE-TDD | B34/B38/B39/B40/B41 | B38/B40/B41/B42/B43 | B38/B40/B41/B42/B43 |
| LTE-FDD | B1/B3/B5/B8 | B1/B3/B5/B7/B8/B20/B28/B32 | B1/B3/B5/B7/B8/B20/B28/B32 |
| Built-in antenna | 4G/5G antenna × 4 | 4G/5G antenna*4, Wi-Fi antenna(MU MIMO)*6 | 4G/5G antenna*8, Wi-Fi antenna(MU MIMO)*4 |
| WCDMA | B1/B2/B5/B8 | B1/B5/B8 | |
| Max data rates | 5G NSA Sub-6: 2.2 Gbp(DL)/575 Mbps (UL), 5G SA Sub-6: 2Gbps (DL)/ 1Gbps(UL), LTE: 400 Mbps (DL)/150 Mbps (UL) |
5G NSA Sub-6: 3.2Gbps (DL)/600 Mbps (UL) 5G SA Sub-6: 2.4Gbps (DL)/900 Mbps (UL) LTE: 1.6 Gbps (DL)/200 Mbps (UL) WCDMA: 42 Mbps (DL)/5.76 Mbps (UL) |
5G NSA Sub-6:3.74Gbps (DL)/1.46Gbps (UL) 5G SA Sub-6: 4.67Gbps (DL)/2.5Gbps (UL) LTE: 1.4Gbps (DL)/211Mbps (UL) WCDMA: 42 Mbps (DL)/5.76 Mbps (UL) |
| Wireless | |||
| Standard | Wi-Fi 5, 802.11 a/b/g/n/ac | Wi-Fi 6 802.11 a/b/g/n/ac/ax | Wi-Fi 6 802.11 a/b/g/n/ac/ax |
| 2.4 GHz | 2 × 2 MIMO, 300Mbps | 2*2 MIMO, 576Mbps | 4*4 MIMO, 1200Mbps |
| 5 GHz | 2 × 2 MIMO, 866Mbps | 802.11 a/b/g/n/ac/ax, 4*4 MIMO, 4804Mbps | 4*4 MIMO, 2400Mbps |
| Max User | 64 | 128 | 64 |
| Built-in antenna | Wi-Fi antenna × 4 (MU MIMO) | 4G/5G antenna*4, Wi-Fi antenna(MU MIMO)*6 | 4G/5G antenna*8, Wi-Fi antenna(MU MIMO)*4 |
| Interface | |||
| LED | Power, Wi-Fi, 4G, 5G | Power, Wi-Fi, 4G, 5G | Power, Wi-Fi, 4G, 5G |
| Button | RESET, Power, WPS | RESET, Power, WPS | RESET, Power, WPS |
| SIM | Micro SIM | 4FF SIM (Nano SIM) | 4FF SIM(Nano SIM) |
| Ethernet | 1 GigE LAN, 1 GigE WAN/LAN | 1*10/100/1000Mbps LAN, 1*10/100/1000/2500Mbps LAN/WAN | 1*10/100/1000Mbps LAN, 1*10/100/1000Mbps LAN/WAN |
| Power Supply | |||
| Power input | Power adaptor, DC socket | Power adaptor, DC socket | Power adaptor, DC socket |
| Voltage | 12V/1.5A | +12VDC/3A | +12VDC/2A |
| Others | |||
| Weight | Approx. 450g | About 800g | About 610g (without power adapter) |
| Size | 175 × 175 × 48.5mm | 100mm* 100mm* 205mm | 94.3mm* 107.1mm* 186.5mm |
| Operating temperature | -10～+45°C | -10ºC+45ºC | -10ºC+55ºC |
| Storage temperature | -40～+70°C | -30ºC+75ºC | -20ºC+70ºC |
| Relative humidity | ≤ 95%(no condensing) | ≤95% | ≤95% |
