Cellular Router
H8951 4G Cellular VPN Router
  • LTE Cat4/WiFi/Ethernet link-backup for Internet auto-failover
  • Advanced VPN protocols integrated, provide secure network
  • Support RS-232/RS-485
  • Support Hongdian Wedora RMS for cloud based management
Product Introduction
H8951 4G Cellular VPN Router is the staring product among the Hongdian's incredible wireless communication product family, dedicated for professional M2M & IoT applications. It provides excellent wireless communication solution to customer by connecting their end devices towards their business success.  It supports RS-232 or RS-485 interface, with ultra-high cost performance. It has been approved by global customers who are using its cellular based connection solution for all their assets/machines to get online, Wi-Fi station and Ethernet WAN can also be configured to help you build up different network topologies. Plus Links auto-failover, VPN data encryption, and multi-VPN tunnel backup machanism, giving you a secure and extremely reliable networking solution.
  • Single SIM cold/hot backup, cellular/wired backup
  • 1 x LAN port & 1 x WAN port
  • 5-36V DC Wide range power input
  • Compact design
  • VPN
  • Support GRE/EoIP/L2TP/PPTP/IPsec/DMVPN/OpenVPN
  • GRE over IPsec, IPsec over PPTP/L2TP
  • IPsec with X.509 CA
  • Stateful GRE
Network Flexibility
  • Support 4G+/4G/3G/2G network,
  • Support worldwide band
  • Support WAN, PPPoE, Static IP, DHCP client
  • Support 802.11b/g/n
Advance Feature
  • Static routing, Policy routing, RIPv2, OSPF, BGP
  • Support DNS proxy  Dynamic DNS (DDNS)
  • LCP/ICMP/flow/heartbeat check, ensure network usability
  • Hardware Watchdog
  • Multiple VLAN
  • Load balancing, QoS, NTP
  • Support IPV6
  • Support Radius, TACACS+
  • Support schedule task
Management
  • Hongdian Wedora RMS, encrypted connection, remote access to device’s GUI/CLI
  • Remote access to end device’s GUI/CLI
  • Support WEB, CLI, SSH local/remote access
  • Support IPfix
  • Support local/remote firmware and patch update
  • Support configuration backup and import
  • Local/Remote log for easy debugging
  • Support SNMPv2/v3
Hardware
CPU MIPS 24Kc @580 MHz
RAM 128MB
FLASH 16MB
Cellular Interface
Modem 1 x LTE CAT4
Number of antennas 2
Connector SMA-K
SIM 1 x Mini SIM (2FF)
Ethernet Interface
Number of ports 2 x 10/100 Mbps, Ethernet
Configuration 2 x LAN or 1 x LAN + 1 x WAN
PoE output N/A
Wireless interface
Standards 802.11b/g/n, AP or station mode
Frequency bands 2.4 GHz
Speed 150Mbps
Security WEP, WPA, WPA2
Encryption 64/128 AES, TKIP
Antennas 1
Connector SMA-K
GNSS interface
Number of antennas N/A
Connector
Dead Reckoning
Seiral interface
Type 1 x RS-232 or 1 x RS-485 serial port
Socket form 1 x 6-pin 3.5 mm female socket
Signal definition RX,TX,GND (RS-232)
A+,B-,GND (RS-485)
Baudrate RS-232 (300-115200bps)
RS-485 (300-115200bps)
Software
Auto fail-over Between:
Cellular and WAN
Cellular and Wi-Fi (station mode)
WAN and Wi-Fi (station mode)
Network protocols PPP, PPPoE, TCP, UDP, IPv4, IPv6, SSL, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, Telnet, SSH, DDNS, etc.
Network APN, VPDN, VLAN, QoS
Routing Static Routing, Policy routing, RIP, OSPF and BGP, etc.
Firewall NAT, PAT, DMZ, Port Forword IP/Domain/MAC Filter, Access Control List
VPN PPTP/L2TP/GRE/IPSec/OpenVPN/DMVPN/WireGuard
Ipsec Encryption DES, 3DES, AES128, AES192, AES256
OpenVPN Encryption BF-CBC, DES-CBC, RC2-CBC, DES-EDE-CBC, DES-EDE3-CBC, DESX-CBC, RC2-40-CBC, CAST5-CBC, RC2-64-CBC, AES-128-CBC,
AES-192-CBC, AES-256-CBC, SEED-CBC
Remote Management HTTP, Telnet, SSH, SMS, SNMP V1/V2/V3, SNMP TRAP, Hongdian Wedora Cloud Platform, SDLAN
Serial ports function Transparent, Modbus RTU, etc.
Power Supply and Consumption
Power Connector DC socket
Voltage input +5V~+36V DC
Power consumption Idle: 100mA@12V DC
Data transceiving: 350mA@12V DC
Others
Reset button Yes
LED indicators 4 x indicators for WiFi, RF, NET, SYS
Hardware watchdog Yes
Physical Characteristics
Ingress protection IP30
Housing & Weight Metal, 300g
Dimension 99.7×98.8×23.4(mm)
Installations Desktop, wall mounting
Operating temperature -30 ~ +75℃
Storage temperature -40 ~ +85 °C
Relative humidity 0~95%(no condensation)
EMC
ESD EN61000-4-2, level3
RS EN 61000-4-3, level3
EFT EN 61000-4-4, level3
CS EN 61000-4-6, level3
Certifications
(*In progress)
CE, FCC, AT&T, Verizon, T-mobile
File Name
Hongdian Application Guide - H8951-Link Backup-WLAN_Modem
Hongdian Specification-H8951 4G Cellular VPN Router-2024
Hongdian User Manual-H8951 4G Cellular VPN Router-2024
Hongdian Datasheet-H8951 4G Cellualr VPN Router-2024V1.0
Product Part No. Network Frequency Interface Certification Region
SIM RJ45 WLAN
H8951
4G Cellular VPN Router
H8951-L4-ENEA LTE Cat 4 4G( LTE-FDD): B1/B3/B5/B7/B8/B20
4G (LTE-TDD): B38/B40/B41
3G: B1/B5/B8
2G: B3/B8
1 2 Wi-Fi 4 CE, RoHS, E-mark* Europe, the Middle East, Africa, Korea, Thailand, India, Malaysia
H8951-L1-ENEA LTE Cat 1 FCC, IC, PTCRB North America
H8951-L4-ENSA LTE Cat 4 4G (FDD-LTE): B1/B2/B3/B4/B5/B7/ B8/B28
4G (LTE-TDD): B40
3G: B2/B3/B5/B8
RCM*, Anatel* Oceania, South America
H8951-L4-ENNA LTE Cat 4 4G( LTE-FDD): B2/B4/B5/B12/B13/B25/B26;
3G: B2/B4/B5
FCC, IC, PTCRB North America
H8951-L1-ENNA LTE Cat 1
H8951-L4-ENJP LTE Cat 4 4G (FDD-LTE): B1/B3/B8/B18/B19/B26/B28
4G (LTE-TDD): B39/B41
3G: B1/B6/B8/B19
VCCI*, JATE*, TELEC* Japan
For more detailed information about the frequency or any specific requirement, please contact your sales representitive.
